MODEL GALEX 553RC
DRIL DIAMETER
(6.0" - 10.0")**
DRILLING DEPTH
Up To 1800-2000 Feet**
HYDRAULIC OIL TANK CAPACITY
600 LTRS
MAST CAPACITY
Approx. 26 Feet (7.92 Mtrs)
MAST HEIGHT
Approx. 9.34 Mtrs
MAST CONSTRUCTION
10 X 3 Structural Channel Supported By Square Pipe
WATER PUMP
120 LPM
HYDRAULIC JACK
125mm- 4 Nos, 125mm-1 Nos, Mast Cylinder 180mm, 75mm Back Out Cylinder
HYDRAULIC WINCH
Attached Gearbox Powered By Hydraulic Motor, Capacity Up To 1 Ton.
HAMMER VICE
Heavy Structural Of Plates With 3 To 4 Attachable Jaws, 150mm,160mm,180mm And 200mm Hammer May Be Opened.
APPLICATION
Water Well Drilling, Mining Application
HYDRAULIC DRIVE SYSTEM
(Power By Tata Cummins Engine 180HP)***
ROTARY HEAD GEARBOX
Indigenous rotary head design, omt315 hydraulic motor used for drive gearbox with torque of 230nm(max)* at 2000psi.
HYDRAULIC CIRCUIT
indigenous hydraulic circuit design, pressure up to 3500psi.
